Sensor
1/2.8" 2.16 MP CMOS
Video Format
1080p : 60 / 50 / 30 / 25
720p : 60 / 50 / 30
Video Output (HD) Interface
3G-SDI / HDMI / Ethernet / USB3.0
Horizontal Viewing Angle
57°
Vertical Viewing Angle
32.1°
Diagonal Viewing Angle
65.4°
Focal Length
5.33mm~110mm
Shutter Speed
1/1 ~ 1/10,000 sec
Minimum Object Distance
Wide: 0.5M / Tele: 1.5M
Minimum Illumination
1.0 lux (F1.6, 50IRE, 30fps)
Focus System
Auto / Manual / Smart AF
Gain Control
Auto / Manual
White Balance
Auto / Manual
Exposure Control
Auto / Manual
Panning Angle
+170° ~ -170°
Tilting Angle
+90° ~ -30°
IP Stream
Main : H.264 1080p 60
Second : H.264 640x360p 30
Webpage Preview: 1280x720 30
USB Compression
H.264 / MJPEG
IP Protocol
RTSP / RTMP / RTMPS / MPEG-TS / SRT
Output
Ethernet / USB 3.0 / HDMI / SDI
Compression Format
AAC / PCM
Interface
RS-232 / RS-422 / Ethernet / USB / Remote
Protocol
VISCA / VISCAIP / ONVIF
Power Consumption
PoE : 10W
DC In : 9W
Dimension (WxHxD)
6.85" x 7.76" x 7.09"
(174 x 197 x 180 mm)
