Video Format
2160p : 59.94 / 50 / 29.97 / 25
1080p : 59.94 / 50 / 29.97 / 25
720p : 59.94 / 50 / 29.97 / 25
1080i : 59.94 / 50
Video Output (HD) Interface
HDMI, Ethernet, 3G-SDI, USB
Horizontal Viewing Angle
81°
Vertical Viewing Angle
50°
Diagonal Viewing Angle
90°
Focal Length
3.4 ~ 43.3 mm
Shutter Speed
1 / 25 ~ 1 / 10,000 sec
Minimum Object Distance
Tele :1m / Wide : 0.1m
Minimum Illumination
1 lux (F1.8, 50IRE, 30fps)
Focus System
Auto, Manual
Gain Control
Auto, Manual
White Balance
Auto, Manual
Exposure Control
Auto, Manual
Panning Angle
+170 ~ -170°
Panning Speed
0.1°~100° / sec
Tilting Speed
0.1° / s ~ 60° / sec
HDMI/3G-SDI
2160p60 / 1080p60
IP Stream
Main : 2160p60
Second : 480p30
IP Compression
H.264/ HEVC(H.265)
USB Compression
H.264 / MJPEG / NV12
IP Protocol
HTTP/ RTSP / RTMP / RTMPS / SRT
Audio Output
Ethernet / USB / HDMI / SDI
Audio Compression Format
USB : PCM
Interface
RS-232 / Ethernet / USB
Power consumption
PoE : 15W
DC In : 14W
Dimension
7.5" x 7.3" x 5.7"
(190 × 185 × 144 mm)
