PTZ Camera Sensor
1 / 2.8" 2.16MP CMOS
PTZ Camera Video Format
1080p60/ 50/ 30/ 25
720p60/ 50
Video Output (HD) Interface
HDMI, Ethernet, 3G-SDI, USB 3.0
PTZ Camera Horizontal Viewing Angle
58.7°
PTZ Camera Vertical Viewing Angle
33°
Diagonal Viewing Angle
67.3°
PTZ Camera Aperture
F1.6 ~ F2.8
PTZ Camera Focal Length
4.9mm ~ 94mm
Shutter Speed
1 / 25 ~ 1 / 10,000 sec
Minimum Object Distance
500mm
Minimum Illumination
1 lux (F1.6, 50IRE, 30fps)
Focus System
Auto, manual
Gain Control
Auto, manual
White Balance
Auto, manual
Exposure Control
Auto, manual
Auto Tracking
Everywhere / Stage / Partition
Auto Framing
Everywhere / Partition
Panoramic Camera Sensor
1 / 2.8" 2MP CMOS
Panoramic Camera Video Format
720p30
Panoramic Camera Horizontal Viewing Angle
111°
Panoramic Camera Vertical Viewing Angle
62°
Panoramic Camera Aperture
F2.4
Panoramic Camera Focal Length
3.1mm
Panning Angle
+170 ~ -170°
Panning Speed
0.2~120° / sec
Tilting Speed
0.2~80° / sec
IP Stream
PTZ Camera
Main: 1080p60
Second: 720p30
Panoramic Camera: 720p30
IP Protocol
NDI HX3 / NDI HX2 / HTTP / RTSP / RTMP / RTMPS / SRT
Audio Input
Line In / MIC In
Audio Output
Ethernet / USB 3.0 / HDMI / SDI
Audio Compression Format
AAC / PCM
Interface
RS-232 / Ethernet / USB 3.0
Protocol
VISCA / ONVIF / NDI
Power Consumption
PoE: 11W
DC In: 10W
Dimension
7.5” x 7.3” x 5.4”
(190 ×185 ×138 mm)
