Video Format
2160p : 30 / 25
1080p : 60 / 50 / 30 / 25
720p : 60 / 50
Video Output (HD) Interface
HDMI / Ethernet / 3G-SDI /
USB 3.0
Horizontal Viewing Angle
58.7°
Vertical Viewing Angle
33°
Diagonal Viewing Angle
67.3°
Focal Length
4.9 mm ~ 94 mm
Shutter Speed
1/25 ~ 1/10,000 sec
Minimum Object Distance
1000 mm
Minimum Illumination
1 Lux (F1.6, 50IRE, 30fps)
Focus System
Auto / Manual
Gain Control
Auto / Manual
White Balance
Auto / Manual
Exposure Control
Auto / Manual
Panning Angle
+170 ~ -170°
Panning Speed
0.2 ~ 120°/sec
Tilting Speed
0.2 ~ 60°/sec
IP Stream
PTZ Camera
Main：2160p 30 / 1080p 60
Second：720p 30
IP Compression
HEVC (H.265) / H.264
IP Protocol
HTTP / RTSP / RTMP / RTMPS / SRT
Audio Output
Ethernet / USB 3.0 / HDMI / SDI
Audio Compression Format
AAC / PCM
Interface
RS-232 / Ethernet / USB 3.0
Protocol
VISCA / VISCA over IP
Power Consumption
PoE: 11W
DC In: 10W
Dimension
7.5" x 7.3" x 5.4"
(190 ×185 ×138 mm)
