Sensor
1/1.8" 9.17 MP CMOS
Video Format
2160p : 60 / 59.94 / 50 / 30 / 29.97 / 25
1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25
720p : 60 / 59.94 / 50 / 30 / 29.97 / 25
1080i : 60 / 59.94 / 50
Video Output (HD) Interface
HDMI 2.0, Ethernet,
USB 3.0 (USB 2.0 compatible)
Pixel Zoom
2x for 1080p (1920x1080)
3x for 720p (1280x720)
Horizontal Viewing Angle
102°
Vertical Viewing Angle
57.4°
Diagonal Viewing Angle
117°
Shutter Speed
1 ~ 1/10,000 sec
Minimum Object Distance
30 cm
Minimum Illumination
0.05 lux (F1.6, 50IRE, 30fps)
Gain Control
Auto / Manual
White Balance
Auto / Manual
Exposure Control
Auto / Manual
Multiple Video Stream
HEVC 4K 59.94fps
H.264 1080p 59.94fps
H.264 640x360 29.97fps
Audio Compression Format
IP: G.711 / USB: PCM
Control Interface
Ethernet / USB / Remote
Control Protocol
VISCA over IP / ONVIF / UVC
Video Stream
RTSP / RTMP / RTMPS /
MPEG-TS / SRT
Video Compression
HEVC(H.265) / H.264 / MJPEG
Audio In
Line In / Mic In
(Phone Jack 3.5mm x1)
Audio Out
Ethernet / HDMI / USB3.0
Power Consumption
PoE: 11W
DC In: 10W
Dimensions
4.4" x 2.8" x 2.0"
(113 x 70 x 51 mm)
Package Contents
Camera
Instruction for installation
Power Adapter
AC Power Cord Bracket accessory kit
3PIN to 2PIN adapter (For Japan only)
Bracket accessory kit
