Sensor
1/2.8" 2.16MP CMOS
Video Format
1080p: 60 / 59.94 / 50 / 30 / 29.97 / 25
1080i: 60 / 59.94 / 50
720p: 60 / 59.94 / 50
Video Output (HD) Interface
3G-SDI / HDMI / Ethernet
Viewing Angle
57° (H) 32.1° (V) 65.4° (D)
Focal Length
5.33mm~110mm
Shutter Speed
1/1 ~ 1/10,000 sec
Minimum Object Distance
1.5m (Wide/Tele)
Minimum Illumination
1.0 lux (F1.6, 50IRE, 30fps)
Focus System
Auto / Manual / Smart AF
Gain Control
Auto / Manual
White Balance
Auto / Manual
Exposure Control
Auto / Manual
Panning Angle
+170° ~ -170°
Tilting Angle
+90° ~ -30°
IP Stream
(NDI HX Stream)
1080p 60fps, 640x30 30fps
(IP Stream)
H.264 1080p 60fps
H.264 / MJPEG D1 30fps
IP Compression
H.264 / MJPEG
IP Protocol
NDI HX2 / RTSP / RTMP / RTMPS / MPEG-TS / SRT
Audio Input
Line In / MIC In
Audio Output
Ethernet / SDI / HDMI
Audio Compression Format
AAC / G.711
Interface
RS-232 / RS-422 / Ethernet
Protocol
NDI / VISCA / VISCAIP / PELCO D / ONVIF
Power Consumption
PoE: 18.5W
DC In: 17W
Dimensions (W x H x D)
6.9" x 7.3" x 7.3"
(174 x 186 x 187 mm)
