號碼 / 訊號
2* HDMI (HDCP Compliant)
2* 3G-SDI
連結
Female HDMI type-A / 3G-SDI
解析度範圍
HDMI Input 1: 720p~2160p 60fps, 1920x1200(RB)
Others: 720p~1080p 60fps
IP 來源 / USB 攝影機
Lumens IP PTZ / Box Camera
RTSP Source (H.264 1080p 60/30fps)
USB Camera (MJPEG 1080p 30fps)
影片壓縮
H.264/AVC 4:2:0 8bit color
Encoding Profile: High, Main, Baseline
號碼 / 訊號
3* H.264/AVC Digital Video over Ethernet
2* HDMI Digital Video
1* HDMI Pass-through (up to 4K)
檔案類型
H.264 and AAC in an MP4 container, JPEG
號碼 / 訊號
1* Line In (Stereo Unbalanced Audio, 3.5mm Phone Jack)
2* Combo (XLR/TRS, Balanced Audio, Line in/ Mic in, Support +48V Phantom Power)
IP Audio Source (RTSP, AAC-Raw, 16K/44.1K/48K)
Support UAC
號碼 / 訊號
1* stereo, Unbalanced 3.5mm Phone Jack
2* stereo, Digital De-embedded Audio from HDMI
USB
1* USB 2.0 Type A
4* USB 3.0 Type A
Support USB Storage, USB Camera, USB Mic. USB Mouse, Keyboard, HID Touch Display
乙太網路主機埠
1* female RJ-45
10/1001000 Base-T High/Full Duplex
串流協定
Pull: RTSP
Push: RTMP / RTMPS / MPEG-TS, SRT
TCP, UDP, HTTP
DHCP Client
支援 IP 來源
Lumens IP Camera, RTSP
場景切換
Yes, preset for layout, background, and overlay
佈局開關
Yes,( Single, PIP, and PBP)
疊加層
Yes, PNG overlay or system time overlay
檔案備份
FTP / SFTP / NAS(CIFS/SMB, NFS)/ WebDAV /Copy to USB Flash Drive
內容管理系統
Panopto / OpenCast / Kaltura
註解
Yes, annotations can be added to the Live screen. It also allows for screen capture and recording.
註解工具
Freehand, Arrows, Line, Square, Circle, Text(English), Highlight, Sportlight, Erase, Freeze..etc
尺寸：（寬×高×深）
Standard 1u rack
dimensions
432mm (W) x 49.4mm (H) x 218mm(D)
(17" x 1.9" x 8.5")
